Flux + Testkube: GitOps Testing is here

Feb 1, 2023
10 mins
read
Adopt the GitOps development process when creating tests for your cloud native application using Testkube and Flux!
Flux + Testkube: GitOps Testing is here
Share on Twitter
Share on LinkedIn
Share on Reddit
Share on HackerNews
Copy URL

Table of Contents

Want to learn more about this topic? Check out our Office Hours sessions!

Get Started with Testkube Pro

## Introduction: Challenges to GitOps Cloud Native Testing

One of the major trends in contemporary cloud native application development is the adoption of GitOps; managing the state of your Kubernetes cluster(s) in Git - with all the bells and whistles provided by modern Git platforms like GitHub and GitLab in regard to workflows, auditing, security, tooling, etc. Tools like ArgoCD or Flux are used to do the heavy lifting of keeping your Kubernetes cluster in sync with your Git repository; as soon as difference is detected between Git and your cluster it is deployed to ensure that your repository is the source-of-truth for your runtime environment.

Don’t you agree that it’s time to move testing and related activities into this paradigm also? Exactly! We at Kubeshop are working hard to provide you with the first GitOps-friendly Cloud-native test orchestration/execution framework - Testkube - to ensure that your QA efforts align with this new and shiny approach to application configuration and cluster configuration management. Combined with the GitOps approach described above, Testkube will include your test artifacts and application configuration in the state of your cluster and make git the source of truth for these test artifacts. And it’s Open-Source too. For more on Testkube, check out the introduction blog, ["Hello Testkube"](https://kubeshop.io/blog/hello-testkube-power-to-testers-on-k8s).

Benefits of the GitOps approach:

1.  Since your tests are included in the state of your cluster you are always able to validate that your application components/services work as required.
2.  Since tests are executed from inside your cluster there is no need to expose services under test externally purely for the purpose of being able to test them.
3.  Tests in your cluster are always in sync with the external tooling used for authoring
4.  Test execution is not strictly tied to CI but can also be triggered manually for ad-hoc validations or via internal triggers (Kubernetes events)
5.  You can leverage all your existing test automation assets from Postman, or Cypress (even for end-to-end testing), or … through executor plugins.

Conceptually, this can be illustrated as follows:


## GitOps Tutorial

Let’s see this in action - here comes a step-by-step walkthrough to get this in place for the automated application deployment and execution of Postman collections in a local Kind cluster to test.

Let’s start with setting things up for our GitOps-powered testing machine!

### Installations for GitOps Testing

#### 1. [Fork the example repository](https://github.com/kubeshop/testkube-flux/fork) and clone it locally

```sh
git clone https://github.com/$GITHUB_USER/testkube-flux.git
```

#### 2. Start a Kubernetes cluster
You can use Minikube, Kind or any managed cluster with a cloud provider (EKS, GKE, etc). In this example we're using [Kind](https://kind.sigs.k8s.io/).

```sh
kind create cluster
```

#### 3. Create a Github Classic Token:
Must be of type [__Classic__](https://docs.github.com/en/authentication/keeping-your-account-and-data-secure/creating-a-personal-access-token#creating-a-personal-access-token-classic) (i.e. starts with `ghp_`)
```sh
GITHUB_TOKEN=<ghp_>
GITHUB_USER=<username>
```

And export the environment variables in your terminal.

#### 4. Install Flux in the cluster and connect it to the repository
Install the [Flux CLI](https://fluxcd.io/flux/installation/) and run:

```sh
flux bootstrap github \
--owner=$GITHUB_USER \
--repository=testkube-flux \
--path=cluster \
--personal
```

#### 5. Create a Flux Source and a Kusktomize Controller
The following command will create Flux source to tell Flux to apply changes that are created in your repository:
```sh
flux create source git testkube-tests \
--url=https://github.com/$GITHUB_USER/testkube-flux \
--branch=main \
--interval=30s \
--export > ./cluster/flux-system/sources/testkube-tests/test-source.yaml
```
And now create a Flux Kustomize Controller to apply the Testkube Test CRDs in the cluser using [Kustomize](https://kubernetes.io/docs/tasks/manage-kubernetes-objects/kustomization/):

```sh
flux create kustomization testkube-test \
--target-namespace=testkube \
--source=testkube-tests \
--path="cluster/testkube" \
--prune=true \
--interval=30s \
--export > ./cluster/flux-system/sources/testkube-tests/testkube-kustomization.yaml
```

#### 6. Install Testkube in the cluster

Install the Testkube CLI from https://kubeshop.github.io/testkube/installing

And run the following command to install Testkube and its components in the cluster:

```sh
testkube install
```

#### 7. Create a `Test CRD` with `testkube` CLI

In this example the test being used is a Postman test, which you can find in `/img/server/tests/postman-collection.json`.

To create a Kubernetes CRD for the test, run:

```sh
testkube generate tests-crds img/server/tests/postman-collection.json > cluster/testkube/server-postman-test.yaml
```

Note: You can [run Testkube from your CI/CD pipeline ](https://kubeshop.github.io/testkube/integrations/testkube-automation) in case you want to automate the creation of the Test CRDs.

#### 8. Add the generated test to the Kustomize file:

The name of the test file created in the previous step is `server-postman-test.yaml`, add that to the Kustomize file located in [`cluster/testkube/kustomization.yaml`](./cluster/testkube/kustomization.yaml):

```diff
apiVersion: kustomize.config.k8s.io/v1beta1
kind: Kustomization
resources:
+ - server-postman-test.yaml
```

#### 9. Push all the changes to your repository

```sh
git pull origin main
git add -A && git commit -m "Configure Testkube tests"
git push
```

#### 10. Your tests should be applied in the cluster

To see if Flux detected your changes run:

```sh
flux get kustomizations --watch
```

And to ensure that the test has been created run:

```sh
testkube get test
NAME | TYPE | CREATED | LABELS |
--------------------------+--------------------+-------------------------------+---------------------------------------------------+
postman-collection-test | postman/collection | 2023-01-30 18:04:13 +0000 UTC | kustomize.toolkit.fluxcd.io/name=testkube-test, |
| | | kustomize.toolkit.fluxcd.io/namespace=flux-system |

```

#### 11. Run your tests
Now that you have deployed your tests in a GitOps fashion to the cluster, you can use Testkube to run the tests for you through multiple ways:
- Using the Testkube CLI
- Using the Testkube Dashboard
- Running Testkube CLI from a CI/CD pipeline

We'll use the Testkube CLI for brevity. Run the following command to run the recently created test:

```sh


testkube run test postman-collection-test


```

And see the test result with:

```sh
testkube get execution postman-collection-test-1


Test execution completed with success in 13.345s
```

## GitOps Takeaways

Once fully realized - using GitOps for testing of Kubernetes applications as described above provides a powerful alternative to a more traditional approach where orchestration is tied to your current CI/CD tooling and not closely aligned with the lifecycle of Kubernetes applications.

This tutorial uses Postman collections for testing an API, but you can bring your a whole suite of tests with you to Testkube. [Check the documentation for the available test types](https://kubeshop.github.io/testkube/category/test-types).

Would love to get your thoughts on the above approach - over-engineering done right? Waste of time? Let us know!

Why not give it a go yourself? [Sign up to Testkube](http://cloud.testkube.io/) and try one of our examples or head over to our [documentation](http://docs.testkube.io/) - if you get stuck or have questions, we’re here to help! Find an answer to your questions in the [Testkube Knowledge Base](https://testkube.io/knowledge-base) or [reach out to us on Discord](https://discord.com/invite/6zupCZFQbe). We’re eager to hear how you use our integrations!

Thank you!
